5mm Clear Acrylic Sheet
Product Specifications – 5mm Clear Acrylic Sheet
| Item | Specification |
|---|---|
| Thickness | 5mm (±0.2mm tolerance) |
| Standard Sheet Size | 1220mm × 2440mm (custom size available) |
| Material | Virgin PMMA (Polymethyl Methacrylate) |
| Color | Clear / Transparent |
| Light Transmission | ≥92% |
| Surface Finish | Glossy on both sides, protective film applied |
| UV Resistance | Yes, suitable for outdoor use |
| Machinability | Supports laser cutting, CNC, drilling, engraving, bonding |
| Type | Cast acrylic (extruded available upon request) |
| Packaging | PE protective film + foam corners + wooden pallet/carton |
5mm Transparent Plastic Panel
Made from high-quality PMMA, this 5mm plastic panel offers outstanding clarity, light transmittance, and structural strength. It’s a go-to choice for display cases, partitions, and protective covers where both visibility and durability are required.
5mm Cast Acrylic Sheet – Full Size or Custom Cut
Available in standard full sheets (1220×2440mm) or custom sizes, this 5mm cast acrylic offers uniform thickness and smooth, glossy surfaces. Ideal for signage, fabrication, and indoor fixtures. Laser/CNC compatible with excellent edge finish.
5mm Plexiglass Board for Indoor & Outdoor Use
This UV-resistant 5mm plexiglass board is suitable for all-weather conditions, making it ideal for outdoor signage, window panels, and patio enclosures. It resists yellowing and warping while maintaining a crystal-clear finish over time.
Thick Clear Acrylic Sheet for Structural Projects
The 5mm thickness makes this acrylic sheet suitable for medium-duty structural uses such as shelving, machine covers, and furniture panels. Rigid yet workable, it offers a safe and lightweight alternative to glass.
Custom Cut 5mm Acrylic Panel – CNC & Laser Ready
Precision-cut 5mm acrylic panels are available in any shape or dimension you need. Professionally machined for smooth edges and clean corners, ideal for retail fabrication, prototyping, or architectural applications.
FAQ – 5mm Acrylic Sheet
Q1: What are the available sizes for the 5mm acrylic sheet?
A: Standard full sheet size is 1220mm × 2440mm (4ft × 8ft). We also offer custom cutting to any size or shape based on your requirements.
Q2: Is the 5mm acrylic sheet suitable for laser cutting and CNC machining?
A: Yes. The 5mm thickness is ideal for both CO₂ laser cutting and CNC routing. It cuts cleanly with polished edges and maintains stability during processing.
Q3: Can I use this 5mm acrylic sheet outdoors?
A: Yes. It is UV-resistant and weatherproof, making it suitable for long-term outdoor applications such as signs, panels, and enclosures.
Q4: What’s the difference between cast and extruded acrylic in 5mm?
A: Cast acrylic has better optical clarity, is easier to polish, and is more stable during laser cutting. Extruded acrylic is more cost-effective and better for straight cuts or mass production.
